Installing the Chassis on a Table or Shelf

This section describes how to attach plastic feet to the
chassis and how to install the chassis on a table or a
shelf.
WARNING: Safety regulations state that the selected
table or shelf must be able to support at least 115.6
kg (255 lb), which is three times the weight of a fully
loaded chassis.

Attaching the Chassis Feet

To install plastic, molded feet on the Switch 4007
chassis, follow these steps:
Using two people, lift the chassis onto the table or
1
shelf.
Position the chassis on its side so that you can access
2
the bottom of the chassis.
Remove the four feet and the four 6-32 Phillips-head
3
screws from the hardware kit.
Using a Phillips screwdriver, screw the feet to the
4
bottom of the chassis. See Figure 9.
S 4007
WITCH
Figure 20 Attaching Plastic Feet to the Switch 4007 Chassis
Installing the Chassis on a Table or Shelf
To install the chassis on a table or on a shelf, follow
these steps:
Lift and turn the chassis upright on its installed plastic
1
feet.
Position the chassis on the table or shelf so that the
2
chassis rests upright squarely on the table or on the
shelf (on all four feet).
Ensure that the front, sides, and the rear of the chas-
3
sis are unobstructed and easy to reach.
