26 C 2: S
HAPTER WITCH

70-km Long Haul GBIC Transceiver

Model Number: 3CGBIC97
The 70-km Gigabit Ethernet GBIC Fiber-Optic
Transceiver connects to the network using a
fiber-optic duplex SC connector.
To learn more about this transceiver, refer to the
70-km Gigabit Ethernet GBIC Transceiver Installation
Guide on the Online Manuals CD-ROM.

Slot Restrictions

Table 4 lists slot restrictions in the Switch 4007
chassis.
Table 4 Slot Restrictions
Module type
Management modules
Switch fabric module
Interface modules

Management Access

You can access and manage your Switch 4007
modules using several methods:
Administration Console
Web Management suite of applications
External SNMP-based network management
application, such as Transcend
Services
4007 M
ODULES
Slot number
8 and 9
7
1, 2, 3, 4, 5, 6
® Network Control
The Administration Console and most of Web
Management are embedded parts of the software
and are available for immediate use to manage your
modules.

Administration Console Access

To manage the module from the Administration
Console:
Log in to the EME.
1
For information about logging in to the EME, see the
Enterprise Management Engine User Guide.
At the prompt, enter:
2
connect <slot>.1
Where is the chassis slot number of the
<slot>
module that you want to manage, and the number
after the decimal point is a subslot number (which is
always 1).
The Administration Console displays the top-level
menu prompt. For example, if you installed a 20-port
100BASE-FX Fast Ethernet Switching Module in slot
4, then the prompt appears as follows:
CB9000@4.1 [20-E/FEN-FX-L2] ():
Enter commands to manage the module.
3
For example, to display a module baseline, enter:
module baseline display
For more information about Administration Console
module commands, see the multiplatform Command
Reference Guide.
