Ventilation Requirements

This section describes ventilation requirements for the
Switch 4007. The chassis contains one fan tray that
contains four fans.
To ensure that installed fans are able to provide
adequate ventilation, maintain at least 7 cm (2.76 in.)
between the sides of the Switch 4007 chassis and the
nearest wall (or other vertical surface). Also provide at
least 91.4 cm (36 in.) behind the chassis to be able to
remove and replace power supplies in the
Switch 4007 chassis.
When you face the front of the Switch 4007 chassis,
the inlet is on the right and the exhaust is on the left.
CAUTION: Operate a Switch 4007 chassis with four
fans running. If one fan in the fan tray fails, replace
the fan tray as soon as possible.

Power Requirements

This section list power requirements for the 930-watt
AC (Model Number 3CB9EP9) power supply.
The Switch 4007 chassis can contain two modular
930-watt power supplies. The 930-watt power
supplies provide AC power to the Switch. The
930-watt power supplies are autosensing. Each
power supply can automatically sense the type of
input voltage to which it is being connected at the
electrical outlet.
Site Requirements for the Switch 4007
Table 5 lists power requirements for each country.
Table 5 Power Requirements Per Country
Location Volts
Asia 220 - 240 Volts
Australia 220 - 240 Volts
Canada 120 Volts
Europe 220 - 230 Volts
Japan 100 Volts
South Africa 220 - 250 Volts
U.K. 240 Volts
U.S.A. 120 Volts
One power cord per power supply is required. The
power cord that you require depends on your country
location.
Table 6 lists the power cords for each country.
Table 6 Power Cord Description for Your Location
Location Power Cord Type
Asia C19/AS3112
Australia C19/AS3112 special- 10A - C19
Canada C19/NEMA 5-20P
Europe C19/CEE7
Japan C19/NEMA 5-15P
South Africa C19/SABS164
U.K. C19/BS1363A
U.S.A. C19/NEMA 5-2 OP
33
Hz Ampere
50 Hz 15-ampere
50 Hz 10-ampere
60 Hz 20-ampere
50 Hz 16-ampere
50/60 Hz 15-ampere
50 Hz 16-ampere
50 Hz 13-ampere
60 Hz 20-ampere
