Table 27 - Avbus Connector "P2" Pin-Out - Avnet Xilinx Spartan-3 User Manual

Copyright © 2003 Avnet, Inc. AVNET and the AV logo are registered trademarks of Avnet, Inc. All other trademarks are property of their respective owners.
Avnet Electronics Marketing
Released
Name FPGA Connector PIN #
PIN #
GEN_IO0 D26 71
GND - 72
LVDS_N1 F23 73
LVDS_P1 F24 74
GND - 75
LVDS_N2 G22 76
LVDS_P2 G23 77
+3.3VDC - 78
LVDS_N4 H20 79
LVDS_P4 H21 80
GND - 81
LVDS_N5 J22 82
LVDS_P5 J23 83
GND - 84
LVDS_N7 K25 85
LVDS_P7 K26 86
GND - 87
GEN_IO5 H23 88
GEN_IO6 K20 89
+3.3VDC - 90
LVDS_N10 M21 91
LVDS_P10 M22 92
GND - 93
LVDS_N12 N21 94
LVDS_P12 N22 95
GND - 96
GEN_IO7 J24 97
GEN_IO8 J25 98
GND - 99
GEN_IO11 L22 100
GEN_IO12 L21 101
+3.3VDC - 102
LVDS_N15 P20 103
LVDS_P15 P19 104
GND - 105
GEN_IO15 M24 106
GEN_IO16 L29 107
GND - 108
LVDS_N16 R22 109
LVDS_P16 R21 110
GND - 111
LVDS_N18 T22 112
LVDS_P18 T21 113
+3.3VDC - 114
LVDS_N20 U24 115
LVDS_P20 U23 116
GND - 117
GEN_IO19 N19 118
GEN_IO20 P25 119
GND - 120
LVDS_N23 W26 121
LVDS_P23 W25 122
GND - 123
LVDS_N25 R20 124
LVDS_P25 R19 125
+3.3VDC - 126
LVDS_N27 T20 127
LVDS_P27 T19 128
GND - 129
GEN_IO21 P24 130
GEN_IO22 P23 131
GND - 132
GEN_IO23 R26 133
GEN_IO24 R24 134
GND - 135
GEN_IO27 U22 136
GEN_IO28 V21 137
+3.3VDC - 138
GEN_IO31 W24 139
GEN_IO32 AA26 140

Table 27 - AvBus Connector "P2" Pin-out

30 of 33
FPGA Name
PIN #
1 - +5VDC
2 E23 LVDS_N0
3 E24 LVDS_P0
4 - GND
5 J20 GEN_IO1
6 F26 GEN_IO2
7 - GND
8 E25 LVDS_N3
9 E26 LVDS_P3
10 - GND
11 H22 GEN_IO3
12 J21 GEN_IO4
13 - +5VDC
14 G20 LVDS_N6
15 G21 LVDS_P6
16 - GND
17 G25 LVDS_N8
18 G26 LVDS_P8
19 - GND
20 H25 LVDS_N9
21 H26 LVDS_P9
22 - GND
23 K23 LVDS_N11
24 K24 LVDS_P11
25 - +5VDC
26 L25 LVDS_N13
27 L26 LVDS_P13
28 - GND
29 K22 GEN_IO9
30 L23 GEN_IO10
31 - GND
32 M19 LVDS_N14
33 M20 LVDS_P14
34 - GND
35 L20 GEN_IO13
36 M26 GEN_IO14
37 - +5VDC
38 N25 GEN_IO17
39 N20 GEN_IO18
40 - GND
41 N23 LVDS_N17
42 N24 LVDS_P17
43 - GND
44 P22 LVDS_N19
45 P21 LVDS_P19
46 - GND
47 T26 LVDS_N21
48 T25 LVDS_P21
49 - +5VDC
50 U26 LVDS_N22
51 U25 LVDS_P22
52 - GND
53 V25 LVDS_N24
54 V24 LVDS_P24
55 - GND
56 V23 LVDS_N26
57 V22 LVDS_P26
58 - GND
59 Y26 LVDS_N28
60 Y25 LVDS_P28
61 - +5VDC
62 AC26 LVDS_N29
63 AC25 LVDS_P29
64 - GND
65 T23 GEN_IO25
66 U20 GEN_IO26
67 - GND
68 V20 GEN_IO29
69 W22 GEN_IO30
70 - GND
Rev 1.0 04/17/2006
Literature # ADS-005104
