LCD Pin # LCD Name
RS# DISP_RS
D0 DISP_D0
D1 DISP_D1
D2 DISP_D2
D3 DISP_D3
D4 DISP_D4
D5 DISP_D5
D6 DISP_D6
D7 DISP_D7
EN# LCD_EN
Table 8 – 2x20 Character LCD Pin-out
15 of 33
FPGA pin#
P8
AE21
AF21
AE20
AF20
AE19
AE18
AE17
AD14
R8
