Band Type
L/S/C band
L/S/C band

6.3 Environmental Specifications

TIMTER™ transmitters meet the environmental requirements shown in Table 15.
Environmental Specifications
Operating temperature (10 mW, 20 mW, 1 W, 5 W, 10 W models)
Operating temperature (20 W and 25 W models)
Non-operating temperature (all models)
Operating humidity
Altitude
6.3.1

EMI Performance

Every Quasonix transmitter is designed to operate reliably and unobtrusively in the most challenging environments.
This includes electromagnetic interference and compatibility (EMI/EMC) requirements. More specifically, all
Quasonix transmitters in the TIMTER™ family (2 cubic inches and above) have been designed to comply with the
following requirements of MIL-STD-461G (and MIL-STD-461E and -461F, when those now-obsolete standards
have been applied):
Requirement
CE101 Conducted Emissions, Audio Frequency Currents, Power Leads
CE102 Conducted Emissions, Radio Frequency Potentials, Power Leads
CE106 Conducted Emissions, Antenna Port
CS101 Conducted Susceptibility, Power Leads
CS114 Conducted Susceptibility, Bulk Cable Injection
CS115 Conducted Susceptibility, Bulk Cable Injection, Impulse Excitation
CS116 Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads
RE101 Radiated Emissions, Magnetic Field
78 Quasonix, Inc.
TIMTER™ Multi-mode Digital Telemetry Transmitter
Wattage
20 mWatt
10 Watt
Table 15: TIMTER™ Environmental Specifications
Table 16: TIMTER™ EMI Compliance
Maximum
Current
0.50 amps 0.45 amps
2.5 amps 1.8 amps
-40°C to +85°C
-40°C to +70°C
-55°C to +100°C
0 to 95% (non-condensing)
Up to 100,000 ft.
Description
Typical Current @ 28
VDC
Description
