Quasonix TIMTER QSX-V Series Installation And Operation Manual page 47

Mnemonic Name
Command
CS Clock Source
DE Differential
Encoding
DIOR Display I/O
Register
Addresses
39 Quasonix, Inc.
TIMTER™ Multi-mode Digital Telemetry Transmitter
Description
Report or set the clock source
Unit always reverts to CS 0
(external) at power-up
Examples:
CS Display the current clock
source
CS 0 Set clock source to
external
CS 1 Set clock source to
internal
When set to internal clock source,
the data source must also be set
to internal via the DS command in
order to have synchronous,
usable data.
Also refer to Appendix C –
Understanding Clock/Data, AC,
and BR
Report or set differential encoding
for the SOQPSK-TG or other
PSK mode
(Differential encoding typically
disabled for other modes)
If LDPC enabled, DE resets to 0.
DE is not valid with MC enabled.
Examples:
DE Report the differential
encoding setting
DE 0 Set differential encoding
OFF
DE 1 Set differential encoding
ON
Displays I/O addresses of
machine registers to make it
easier to debug
Example:
DIOR Displays I/O addresses
Option (s) Setting
Required Saved?
Standard N
Standard Y
Standard N/A
Factory
Default
CS 0
DE 1
N/A
