Table 1: Model Configuration Example - Quasonix TIMTER QSX-V Series Installation And Operation Manual

•
PF Parallel port frequency programming
•
PM Parallel port mode selection
•
Enable hardware presets (specify 2, 4, 8, or 16 – PS2, PS4, PS8, PS16)
PS
•
PW020 RF Output 20 mW (+13 dBm)
•
RH Recall Holdoff
•
RN Randomizer output to baseband connector
•
STDN Supports Spacecraft Tracking and Data Network (PM/BPSK) mode
•
VF Variable FIFO Depth, controls transmitter latency
•
VP Variable power (31 settings, spanning 24 dB), software controlled*
•
WV Wide input voltage range
•
XD External Device Control
Refer to Table 13 in section 4.2.1 for detailed descriptions of each option. Due to input connector pin count
limitations, certain combinations of options are not available. Please contact Quasonix for support in ordering
TIMTER™ options or for information regarding upgrades to TIMTER™ units that you may already own.
The model number identifies the configuration of the unit. For example, model number QSX-VSTT-1100-10-04-
04AB-CF defines a unit configured as shown in Table 1.
Identifiers
QSX
V
S
T
2
1100
10
04
04AB
CF
3 Quasonix, Inc.
TIMTER™ Multi-mode Digital Telemetry Transmitter

Table 1: Model Configuration Example

Quasonix product
Variable bit rate
S band code
TTL clock and data interface code
RS-232 serial control interface: baud rate 57,600
Tier 0 present, Tier I present, Tier II absent, Legacy absent
10 Watt RF output
Pinout code 04
Package code
Clock-free baseband interface option
Description
