Mnemonic Name
Command
AIR Analog Input
Reference
Select
BBCK Check BB Clock
BD Display Bias
Data
BR Bit Rate
36 Quasonix, Inc.
TIMTER™ Multi-mode Digital Telemetry Transmitter
Description
Select the reference level for the
analog input
Examples:
AIR Report the current value
of AIR
AIR 1 Select 1.65V
AIR 0 Select 0V
Displays the current baseband
clock value and source
Example:
BBCK
BB clock rate = 0.999998 Mbps,
src = Int Clk
Refer to section 4.2.1.1.2 for
related BBCK command detail
Display the most recent drain
current, drain voltage, drive bias
voltage, and final bias voltage
Used when the Clock Free (CF)
option is specified and internal
transmitter clock is in use
Report or set the bit rate of the bit
sync that is locking to the
externally applied data
Not to be confused with "IC",
which sets the rate of the
internally generated clock
Bit rate must be below 35 Mbps
to use automatic bit rate detection
Examples:
BR Report the bit rate
BR 5 Set the bit rate to 5 Mbps
BR A Set the bit rate
automatically
Refer to section 4.2.1.1.3 for
related BR command detail
Option (s) Setting
Required Saved?
AI Y
(also
software
Rev J)
Standard N/A
Depends N/A
on Tx
version
CF Y
Factory
Default
AIR 0
N/A
N/A
BR 5
