Note that just turning the RF output on does not guarantee that RF is output. If there is not a valid clock (or in clock
free, if there is no valid data (transitions) from which to derive a clock), then the RF output is Off (unless the unit
has the AC option and the AC command is enabled, in which case a carrier on the current center frequency is
output).
Also, if the unit has an RF On/Off pin that is pulled into the Off state (determined by the current setting of RZ), then
there is no RF output.
Also refer to Appendix C – Understanding Clock/Data, AC, and BR.
4.2.1.1.14 RF Output State – RFS
The RFS command may display the following information, depending on available options, about the connected
transmitter:
RFS
ModCtrlReg shdw = 00007003h
BB_ctl_reg = 00000890h
pa_ctrl_shadow = 00000006h
RF pin = 1 RZ 1 (high = RF on) PA Intfc NOT detected
DP opt 0 PL 1
CF opt 1 CF Normal
EN option 0 EN state 0
AC opt 1 ACS opt 0
AI opt 0 AI state disabled
CE opt 1 RH opt 0
BB rate: 5.000 Mbps
MO 0 FR 1812.5 MHz FO
CS 0 DS 0 IC 5.000
BR 5.000 Mbps (Auto)
RF 1 CC 0 MC 0
DE 0 RA 0 CP A
bb_clk_okay: 1
Power Level = 31.5 dB
Tmpcmp Enabled
RF State: On
BB rate: 5.000 Mbps
TX Enable : 1
Synth_en = TRUE
T4 Atten 0.0 dB
4.2.1.1.15 Set Configuration Priority – SC
The SC command sets or shows the current configuration priority setting. When the transmitter is first powered on,
it loads the default configuration from preset 0. Based on the setting of the SC parameter, the transmitter may look
for a digital switch box sign-on and then attempt to read the frequency, mode, and LDPC settings from the switch
box. This command requires the DSWBX (digital switch box) option to be valid.
Valid SC settings are:
•
1 – Read the switch box (frequency plug) on power up; thereafter, changes from either the switch box or
Terminal interface are allowed.
•
2 – Ignore the switch box (frequency plug) ALWAYS; Only the Terminal interface works until the SC
setting changes.
The default value is SC 1 if the DSWBX option is present on the transmitter.
The default value is SC 2 if the DSWBX option is NOT present on the transmitter.
68 Quasonix, Inc.
TIMTER™ Multi-mode Digital Telemetry Transmitter
bb interface: RS422
AC Off
SC 2
NRF opt 0
OTA rate:
0.068 MHz SD 100
ID pattern currently: PN23
MS 1.000 LP 0.0
DP 0 SI 0 VP 31.5
clock free bitrate: N/A
DL: 4400
DL chk Enabled
Desired RF: On
OTA rate: 5.000 Mbps
Bias Enable: 1
Mod_en = TRUE
PA Atten2 31.5 dB
GPIO_In_reg = 5C02FF37h
CF_auto_ctl_reg = 00000000h
FO opt 1
LD opt 1 LD6 opt 1
5.000 Mbps
HP 31.5
i dac: 5075 q dac: 11362 iqr: -7.0 dB
Synth locked
Last Dsrd RF: On
PA_RF_state = 0
24V Run: 0
Vin_fault_detected = 0
LDPC Off code 2
