7.00" [178mm]
OSC MAX.
8.20"
[208mm]
13.80"
[351mm]
16.2"
[411mm]
12.10"
[306mm]
Tornado OSC Monitor Dimensions
MODEL
Y2-SD*a
2.5" ANSI 150 FLANGE
Y2-SF*A
3.0" ANSI 150 FLANGE
Y2-SG*A
4.0" ANSI 150 FLANGE
©Copyright Task Force Tips LLC 2008-2019
Fig 3.5c
INLET FITTING
TYPE
DN100 PN16
360°
CONTINUOUS
90°
[425mm]
45°
ADDITIONAL
HEIGHT
0.60"
15 mm
0.00"
0 mm
0.16"
4 mm
10
[158mm]
6.20
[153mm]
6.00
16.70
[315mm]
12.40
Fig 3.5d
Electric Tornado RC LT Monitor Dimensions
LIY-300 August 12, 2019 Rev17
185° LEFT
185° RIGHT
90°
45°
