Hardware Kit (not to scale)

The following pieces of hardware are provided on a shrink-wrapped card. Each part is labeled on the card for easy reference.

Table 1. Hardware kit contents

Fasteners

Pulldown Assembly Guide: Getting Started

Buttonhead cap screw (M8 x 15 mm)

Socket head cap screw (M12 x 35 mm)

Socket head cap screw (M5 x 20 mm)

Socket head cap screw (M5 x 12 mm)

Flat washer (9 mm internal diameter)

Set screw (M8 x 6 mm)
