Precor Discovery Plate Loaded Series Assembly Manual page 22
Pulldown
Hide thumbs
Also See for Discovery Plate Loaded Series:
- Assembly manual (40 pages) ,
- Owner's manual (36 pages) ,
- Assembly manual (36 pages)
Table of Contents
Advertisement
Available languages
Available languages
Fasteners
Pulldown Assembly Guide: Getting Started
Flat washer (13 mm internal diameter)
Flat head cap screw (M10 x 25 mm)
Hex head cap screw (⁵₁₆-inch x 1¹₂-inch)
Flat head cap screw (M6 x 30 mm)
Flat washer (11 mm internal diameter)
Socket head cap screw (M10 x 30 mm)
Axle mount end
Quantity
16
2
4
4
2
2
4
4
