IEEE 1284 Parallel Interface

Operating Modes

The 1284 supports three operating modes, which are determined by negotiation
between the printer and the host.
Compatibility Mode
This mode provides compatibility with Centronics–like host I/O (see Table 5–3 ).
Data is transferred from the host to the printer in 8–bit bytes over the data lines.
Compatibility Mode can be combined with Nibble and Byte Modes to provide
bidirectional communication.
Nibble Mode
Eight bits equals one byte. When a byte of data is sent to the printer, the eight
bits are sent over eight data lines.
Some devices cannot send data over their eight data lines. To bypass this, the
1284 permits data to be sent as half a byte over four status lines. (Half a byte
equals one nibble.) Two sequential four–bit nibbles are sent over the lines.
Data is transferred from printer to host in four-bit nibbles over the status lines,
and the host controls the transmission.
Byte Mode
The printer and host send data to each other along eight data lines (one bit per line).
If bidirectional communication is supported by the printer and the host, the host
will take control of the data transfer.
Interfaces 5–9
