Serial Matrix Emulation
Control Code 06
Control Code 06 defines the function of ASCII code 06 hex (ACK). You can select
an alternate line spacing of 6, 8 or 10.3 LPI.
Define CR Code
This option controls the action of the printer when it receives a Carriage Return
code (0D hex) from the host computer. If this feature is enabled, each time the
printer receives a Carriage Return, it inserts an additional Line Feed code (0A
hex) into the data stream. Do not use this feature if the host computer sends Line
Feeds to the printer.
CR = CR does not insert an extra Line Feed after each Carriage Return.
CR = CR + LF inserts an extra Line Feed after each Carriage Return.
The next print position will be print position 1 of the next line.
Auto LF
The Auto LF option defines the printer actions when print data is received past
the forms width setting.
DISABLE discards any data past the forms width.
ENABLE performs an automatic carriage return and line feed when data
is received past the forms width.
Overstrike
Overstrike determines the action required when a line is printed over a previous
line because a carriage return was received without a line feed.
DISABLE replaces the characters from the first line with the second line.
ENABLE prints the second line on top of the first line.
4–72 Configuration Menus
