Spc Coax Params Menu - Printronix ProLine 5 Series Manual

SPC Coax Params
Simp Prot Conv
SPC Coax
Params
Logical Buf Size Image Buff Size
1920*
960
2560
3440
3564
Column 132
Wrap
Disable*
Enable
Logical Buff Size
Refers to the size of the printer buffer which should be set the same as the host
screen (buffer) size. If the host screen size is unknown, use 1920.
Image Buff Size
This option refers to the printer base buffer size. This size must be set to a value
greater than or equal to the Logical Buffer Size.
Intervention Reg
Select SEND TO HOST to have the printer send a signal to the host whenever
any of the following events occur:
1. The printer faults.
2. HOLD Mode Time–Out
3. CANCEL PRINT key is pressed.
Configuration Menus
* = Factory default
Intervention
Reg
4K* Send to Host*
2K Do Not Send
PA1
Buffer Print Translation Tbl
Disable*
Enable
PA2 Buffer Reprint
4–55
