Appendix C
Electromagnetic immunity
Immunity Test IEC 60601 Test Level
± 2kV for power supply
Electrical fast
line.
transient/burst IEC
± 1kV for input/output
61000-4-4
line.
± 1kV differential Mode.
Surge
± 2kV common mode
IEC 61000-4-5
line.
<5 % Ut(>95 % dip in Ut)
for 0.5 cycle
Voltage dips, short
40 %Ut (60 % dip in Ut)
interruptions and
for 5 cycles
voltage variations
on power supply
70 % Ut(30 % dip in Ut)
input lines IEC
for 25 cycles
61000-4-11
<5% Ut(>95% dip in Ut)
for 5 sec.
Power frequency
(50/60 Hz)
magnetic field 3 A/m
environment
IEC 61000-4-8
NOTE: Ut is the main voltage before application of the test level.
52
Compliance level
± 2kV for power supply
line.
± 1kV for input/output
line.
± 1kV differential Mode.
± 2kV common mode
line.
<5 % Ut(>95 % dip in Ut)
for 0.5 cycle
40 %Ut(60 % dip in Ut)
for 5 cycles
70 % Ut (30 % dip in Ut)
for 25 cycles
<5% Ut (>95% dip in Ut)
for 5 sec.
3 A/m
2049809-001 Rev B
Electromagnetic environment
guidance
Mains power quality should be that of a
typical commercial or hospital environment.
Mains power quality should be that of a
typical commercial or hospital environment.
Mains power quality should be that of a
typical commercial or hospital environment.
If the user of the unit requires continued
operation during power mains interruptions,
it is recommended that the unit be powered
from an uninterruptible power supply or a
battery.
Power frequency magnetic fields should be
at levels characteristic of a typical location in
a typical commercial or hospital.
