Chapter 3:Mini Telemetry Components
Component
18
2049809-001 Rev B
Description
5. Power cord holder clamp:
To hold the power cord.
6. Auxiliary Output Connector
This connector outputs the US, ECG, UA and Mark
signals acquired by telemetry to a compatible
fetal/fetal-maternal Monitor. See "Connecting the
Receiver and Monitor" on page 19 for complete
interconnection details.
As soon as any telemetry mode is detected, the
front panel of the compatible fetal/fetal-maternal
monitor is disabled and all front panel inputs are
ignored. In other words, telemetry and monitor
modes cannot be mixed and matched, you must
use either telemetry or direct monitoring only.
For proper operation with 120, 170, 250 or 250cx
Series monitors, disconnect all transducers from
the front panel of the monitor.
7. Programming Connector
The channel number of receiver can be changed
through the transmitter using programming
connector. For more details, refer to Appendix B.2
of Mini-telemetry service manual.
