Problem
Radio channel number does
not appear in the normal
user screen on transmitter
display
Bad Radio Icon
appears on the
transmitter screen
Bad battery icon
appears on the
transmitter screen
© 2010 by General Electric Company. All rights reserved.
Troubleshooting
Probable Cause
• Currently configured
channel number is outside the
supported range as specified
in service manual.
• Communication between the
system and the radio module
is not established.
• Radio module is defective.
• Transmitter frequency
outside the range of the radio
module.
• Communication between the
system and the radio module
is not established.
• Radio module is defective.
• Transmitter battery pack over
discharged
• Defective battery
• Battery not able to charge
Solution
radio
Contact your Information Technologies
Service Representative.
is
Contact your Information Technologies
Service Representative.
• Connect the power adaptor to the
transmitter and charge for 15 minutes.
Disconnect the power adaptor and
reconnect. Switch on the transmitter
and check if bad battery symbol is
replaced with the battery status.
• Disconnect the battery from the
battery compartment. Refer to section
6.1.1 of Mini-telemetry service manual
for battery replacement procedure.
Reconnect the battery and repeat the
previous step.
• Disconnect the battery from the
battery compartment. Refer to section
6.1.1 of Mini-telemetry service manual
for battery replacement procedure.
Using an external DC source (8.5V and
current limited to 1000mA), charge the
battery for 5 minutes. Reconnect the
battery and repeat the previous step.
• Contact your Information Technologies
Service Representative.
• Replace the battery
