8. Configure
Provides access to menus to set-up passwords, relay activation, temp scale, display contrast, flow
switch, inputs, history time stamps, factory set-up and system information.
>CONFIGURE<
PASSWORD
RELAYS
INPUTS
HISTORY
FLOW SW
8.1 Password
>CONFIGURE PASSWORDS<
ADMIN PASSWORD
USER PASSWORD
USER SET UP
8.2 Relays
>CONFIGURE RELAYS<
RELAY 1
RELAY 2
RELAY 3
RELAY 4
RELAY 5
8.3 Network
>CONFIGURE NETWORK<
IP ADDRESS
IP MASK
GATEWAY
SERVER
HTTP LOCAL
CONTRAST
TEMP SCALE
NETWORK
SYS INFO
FACTORY
MORE RELAYS
HTTP REMOTE
FTP
RESET
18
INPUTS- This screen shows what digital
inputs are available on the unit such as water
meters, flow and drum level alarms.
CONTRAST- This screen allows for adjusting
the display contrast.
FLOW SW- Defines a flow switch to be open
or closed with flow.
FACTORY- A factory only menu
TEMP SCALE- Set between Celsius or
Fahrenheit
HISTORY – Sets the history time stamp
interval.
SYS INFO- Tells unit software specifics.
ADMIN PASSWORD – The administrator
password gives access to all menus except
factory set up.
USER PASSWORD – The user password
allows the user to access HOME menus that
are made available in USER SET UP.
CONFIGURE RELAYS – This menu lets
you choose what available function (timer 1,
conductivity, alarms etc...) activates a
particular relay. When you select a relay a
pop-up screen appears with a list of all
available activation
through.
NETWORK – This menu is used for setting
up the remote
communications and is covered in a
separate manual.
functions to arrow
WebAdvantage
