4.3 Pulse Timer
>SYSTEM 1 TIMER 1 CHANGE<
PULSES
RUN TIME
METER INPUT
4.4 Percent Timer
>SYSTEM 1 TIMER 1 CHANGE<
% OF CYCLE
CYCLE TIME
4.5 Post Bleed Timer
>SYSTEM 1 TIMER 1 CHANGE<
% OF BLEED
LIMIT TIME
4.6 With Bleed Timer
>SYSTEM 1 TIMER 1 CHANGE<
LIMIT TIME
PULSES- The number of contacts from water
meter to count be activating timer.
The amount of timer for the timer
RUN TIME-
to run
METER INPUT-
timers has two water meter inputs you must
select which meter to get contacts from.
% of CYCLE- The percent of the defined cycle
timer that the timer is to be on.
CYCLE TIME-The amount of time in MM:SS that
the cycle is going to be.
% of BLEED- The percent of the post
conductivity bleed time that you want the timer
to run.
LIMIT TIMER- The limit timer is a safety feature
that limits a single feed cycle to the amount of
timer set regardless of the calculated post feed
%.
LIMIT TIMER- This timer starts when the
conductivity bleed starts and turns off when the
bleed stops or until the limit time has been
reached. The time can be set in MM:SS.
