Junction Box
L
N
Gnd
12

WIRING DIAGRAM

SE12DA
BU
BR
BR (Line)
Y (Min. Voltage)
BU
Y
GY (Lamps)
W
R (Med. Voltage)
R
BK (Max. Voltage)
BK
Y
Y
BK
R
W
BU
W
BU
W
BR
BK
W
Switch Operation
POSITION
FUNCTION
No Connection
Off
Brown - Gray
Lamps
(L - 1)
Brown - Yellow
Low Speed
(L - 2)
Medium
Brown - Red
Speed
(L - 3)
Brown - Black
High Speed
(L - 4)
Mechanical Push Buttons
(4 buttons 3 speeds)
12.5uF
Y
High Voltage
GY
Max. Voltage
BK
R
Medium Voltage
W
Minimum Voltage
S40
BU
Common
Y/G
Y/G
Motor
Chassis
Motor
Characteristics
Power Supply
120 VAC
Frequency
60 Hz
Power Absorption 240 Watts
Motor Resistance
(Ohms)
Blue - Black
28.8
±10%
Blue - Gray
30.3
±10%
Blue - Red
37.7
±10%
Blue - White
45.1
±10%
73.4˚F (23˚C)
Room Temp.
