BONFIGLIOLI TECNOINGRANAGGI LC Series Installation, Use And Servicing Manual page 21

5. Restore the plug blanking the hole of the motor adapter into its seat.
Motor Tightening
Locking
shaft torque
bolt
diam. [Nm]
6 / 6.35 M4 5
7 M4 5
8 M4 5
9 / 9.52 M4 5
11 M4 5
12 / 12.7 M4 5
14 M4 5
9
M5 9
11 M6 11
12 / 12.7 M6 11
14 M6 11
15 / 15.875 M6 11
16 M6 11
19 M6 11
24 M6 14
28 M8 20
32 M8 20
Torque Torque
transmitted transmitted
at 20°C at 90°C
[Nm] [Nm]
9 6
9 6
11 8
14 11
19 15
18 14
22 18
20 15
20 15
35 25
35 25
50 45
50 45
120 90
120 90
120 100
160 100
