8 | Operation

8.5 Setting the master user interface

8.5.1 About setting the master user interface

8.5.2 To designate the master user interface (VRV DX and Hydrobox)

Installer and user reference guide
30
For the following conditions, a micro computer controls the air flow direction
which may be different from the display.
The air flow direction can be adjusted in one of the following ways:
▪ The air flow flap itself adjusts its position.
▪ The air flow direction can be fixed by the user.
▪ Automatic and desired position .
WARNING
Never touch the air outlet or the horizontal blades while the swing flap is in
operation. Fingers may become caught or the unit may break down.
NOTICE
▪
The movable limit of the flap is changeable. Contact your dealer for details. (only
for double-flow, multi-flow, corner, ceiling-suspended and wall-mounted).
▪
Avoid operating in the horizontal direction
settle on the ceiling or flap.
The displays of slave user interfaces show
control) and slave user interfaces automatically follow the operation mode
directed by the master user interface.
Only the master user interface can select heating or cooling mode.
1 Press the operation mode selector button of the current master user interface
for 4 seconds. In case this procedure was not yet performed, the procedure
can be executed on the first user interface operated.
Result: The display showing
all slave user interfaces connected to the same outdoor unit flashes.
2 Press the operation mode selector button of the controller that you wish to
designate as the master user interface.
Result: Designation is completed. This user interface is designated as the
master user interface and the display showing
centralised control) vanishes. The displays of other user interfaces show
(change-over under centralised control).
Ceiling suspended units
Wall-mounted units
. It may cause dew or dust to
(change-over under centralised
(change-over under centralised control) of
VRV IV water-cooled system air conditioner
(change-over under
RWEYQ8~14T9Y1B
4P452191-1B – 2020.10
