ADTEK CPM-21 Operation Manual page 9

Press Key
Press Key
Press Key
Press Key
1 3 5 . . -
Phase voltage angle
◎Additional screen display for
V3.0 and above version
VA-VA
VB-VA
VC-VA
1 3 6 . . -
Line voltage angle
◎Additional screen display for
V3.0 and above version
VAB VAB -
VBC-VAB
VCA-VAB
1 3 7 . . -
Current phase angle
◎Additional screen display for
V3.0 and above version
-
IA VA (VAB)
IB-VA (VAB)
IC-VA (VAB)
o . .
T 1 3 1 Display Or
Press Key1 Sec Back to
Measurement screen
Press Press
Down Down
Normal screen
first showed off the voltage value As follows
Press Key
Press Key
Press Key
Press Key
Press Key
8
Power parameters Power parameters
( (
KEY KEY
1 seconds,
Phase voltage and the Average
Phase A voltage
Phase B voltage
Phase C voltage
Average Phase voltage
Active energy
1.4.1-
Power display-1
Total apparent power
Total reactive power
Total active power
Average power factor
Total Active energy
1.4.2-
Power display 2 -
Total apparent power
Total reactive power
Total active power
Average power factor
Total reactive energy
1.4.3-
Total electricity bills display
Total apparent power
Total reactive power
Total active power
Average power factor
Total electricity bill
1.4.4-
Carbon emissions
Total apparent power
Total reactive power
Total active power
Average power factor
Total carbon dioxide(kg)
o . .
T 1 4 1 Display Or
Press Key1 Sec Back to
Measurement screen
) )
