ADTEK CPM-21 Operation Manual page 13

Table A
Table DO Correspond alarm output
0 FREQ : 2 UB :
1 UA :
7 UCA :
9 IA :
8 ULLavg :
14 PB : 15 PC : 16 PSUM :
20 QSUM : 21 SA : 22 SB :
26 PFB : 27 PFC : 28 PFAVG :
30 D QSUM : .
31 D SSUM : .
K 6 -
DO2 Type
Digital Output Type
Set range:
PLS.RE: Reactive Energy
pulse output
AL-HI: High Alarm
AL-LO: Low alarm
DO: 485 Control Force Output
Default PLS.RE :
K 7 -
DO2 Select
Alarm output DO2
corresponding parameter
Set range:
as Table A
K 8 -
DO2 SP
Alarm output points:
Set range:
-199999999~999999999
Default 0.00
4 ULNavg :
3 UC : 5 UAB :
10 IB : 12 Iavg :
11 IC : 13 PA
17 QA : 18 QB : 19 QC :
23 SC : 24 SSUM :
25 PFA :
29 D PSUM : .
32 D I AVG : . .
:
6 UBC :
:
Back T A-1 Display Or
Press
12
NOTE
When the digital output is
selected as pulse output,
the following screen will
appear(K9&K10)
K 9 -
Pulse Con
Pulse constant
Set range: 1 ~ 6000
pulse output constant setting
(output divider) 1 pulse = set
value * 0.1 (kWh / kVARh)
K 10 -
Pulse wld
Pulse width
Set range: 1 ~ 20
Pulse output width =
set value * 10 mS
L 1 -
INIT Restore Default
Set range 0000 9999 :
set 7170 restore default : ,
o
Key1 Sec Back to
Measurement screen
Default 1 :
Default 10 :
~
Default:0
