AD700E
2.1 QUICK START UP
Summary
2.2 QUICK START PROCESS
Chapter 1
P. 5
General information
Chapter 2
P. 7
Important safety information
Chapter 3
P. 12
General Information and Ratings
Chapter 4
P. 15
Mechanical Installation
Chapter 5
P. 21
Power Wiring
Chapter 6
P. 29
Operation
Chapter 7
P. 31
Parameters
Chapter 8
P. 42
Analog and Digital Input Macro
Configurations
Chapter 9
P. 48
Modbus RTU Communications
Chapter 10
P. 50
Technical Data
Chapter 11
P. 54
Trouble Shooting
PREVIOUS VIEW
Step Action
Identify the Enclosure Type, Model Type and ratings of your drive from the
model code on the label. In particular
1 - Check the voltage rating suits the incoming supply
- Check the output current capacity meets or exceeds the full load current
for the intended motor
Unpack and check the drive. Notify the supplier and shipper immediately of
2
any damage.
Ensure correct ambient and environmental conditions for the drive are met
3
by the proposed mounting location.
Install the drive in a suitable cabinet (IP20 Units), ensuring suitable cooling
4
air is available. Mount the drive to the wall or machine (IP66).
Select the correct power and motor cables according to local wiring
5
regulations or code, noting the maximum permissible sizes
If the supply type is IT or corner grounded, disconnect the EMC filter before
6
connecting the supply.
7 Check the supply cable and motor cable for faults or short circuits.
8 Route the cables
Check that the intended motor is suitable for use, noting any precautions
9
recommended by the supplier or manufacturer.
Check the motor terminal box for correct Star or Delta configuration where
10
applicable
Ensure suitable wiring protection is provided by installing a suitable circuit
11
breaker or fuses in the incoming supply line
Connect the power cables, especially ensuring the protective earth
12
connection is made
13 Connect the control cables as required for the application
14 Thoroughly check the installation and wiring
15 Commission the drive parameters
See Section
3.1 Identifying the Drive by Model Number
10.1 Environmental
4.1
General
4.3
Mechanical Dimensions and Mounting – IP20 Open Units
4.4 Guidelines for Enclosure Mounting – IP20 Units
Mechanical Dimensions – IP66 (Nema 4X) Enclosed Units
4.5
Guidelines for mounting (IP66 Units)
4.6
10.2 Rating Tables
5.2 EMC Filter Disconnect
5.6 Motor Terminal Box Connections
10.2 Rating Tables
5.1
Grounding the Drive
5.3 Wiring Precautions
Incoming Power Connection
5.4
5.8
Control Terminal Wiring
5.9 Connection Diagram
Analog and Digital Input Macro Configurations
8
6.1
Managing the Keypad
Parameters
7
2
Page
12
50
15
15
16
17
18
51
22
24
51
21
22
23
25
26
42
29
31
9
