Nidec Answer Drives 700E Installation & Operating Instructions Manual page 10

AD700E
QUICK START – IP20 & IP66 NON SWITCHED
Summary
Chapter 1
P. 5
General information
Connect a Start / Stop switch between control terminals 1 & 2
Chapter 2
P. 7
Important safety information
Chapter 3
P. 12
General Information and Ratings
Close the Switch to Start
Chapter 4
Open to Stop
P. 15
Mechanical Installation
Chapter 5
Connect a potentiometer (5k – 10kΩ) between terminals as shown to vary the speed
P. 21
from P-02 (0Hz default) to P-01 (50 / 60 Hz default)
Power Wiring
Chapter 6
P. 29
Operation
Chapter 7
P. 31
Parameters
Chapter 8
P. 42
Analog and Digital Input Macro
Configurations
Chapter 9
P. 48
Modbus RTU Communications
Chapter 10
P. 50
Technical Data
Chapter 11
P. 54
Trouble Shooting
