QUICK START – IP66 SWITCHED
Summary
Chapter 1
P. 5
General information
Switch the unit on using the isolator switch on the panel.
Chapter 2
P. 7
Important safety information
Chapter 3
P. 12
General Information and Ratings
Chapter 4
P. 15
Mechanical Installation
Chapter 5
P. 21
Power Wiring
Chapter 6
P. 29 The OFF/REV/FWD will enable the output and control the direction of rotation of the motor.
The potentiometer will control the speed.
Operation
Chapter 7
P. 31
Parameters
Chapter 8
P. 42
Analog and Digital Input Macro
Configurations
Chapter 9
P. 48
Modbus RTU Communications
Chapter 10
P. 50
Technical Data
Chapter 11
P. 54
Trouble Shooting
