APPENDIX A.
The following tables provide the pin assignments for the base unit and network interface modules (NIMs).

Base Unit Pinouts

Table A-1. CONSOLE Port Pinouts

Pin Name
1
2
3
4
5
6
7
8
9

Table A-2. SFP Slot Pinouts

Pin Name
1 TGND
2 TX FAULT
3 TX DISABLE
4 MOD DEF(2)
5 MOD DEF(1)
6 MOD DEF(0)
7 RATE SELECT
8 LOS
9 RGND
10 RGND
617006364F1-34A
CONNECTOR PIN DEFINITIONS
DCD Data Carrier Detect (output)
RD Receive Data (output)
TD Transmit Data (input)
DTR Data Terminal Ready (input)
SG Signal Ground
DSR Data Set Ready (output)
RTS Request to Send (input)
CTS Clear to Send (output)
— Unused
Pin
11
12
13
14
15
16
17
18
19
20
Copyright © 2014 ADTRAN, Inc.
Description
Name
RGND
RX-
RX+
RGND
VccR
VccT
TGND
TX+
TX-
TGND
