Optional Battery Backup Unit (P/N 1175044L1) - ADTRAN NetVanta 6360 Hardware Installation Manual

Unit Installation

Optional Battery Backup Unit (P/N 1175044L1)

The ADTRAN battery backup unit (BBU) is an optional device designed as a backup DC power supply for the
NetVanta 6360. The BBU connects to the NetVanta 6360 through a 6-foot charge/discharge, 2-conductor wire
with a keyed modular plug (included with the BBU). The 1175044L1 BBU is a low profile wallmount
configuration. It can be rack mounted with the appropriate 19-inch or 23-inch rackmount adapter brackets. The
19-inch rackmount adapter bracket part number is P/N 1175047L1. The 23-inch rackmount adapter bracket part
number is P/N 1175048L1.
ADTRAN does not recommend using the optional battery backup unit when the
NetVanta 6360 is being powered from a DC source.
Features of the BBU, P/N 1175044L1, include the following:
• No-spill battery design
• Compact wallmount or rackmount box
• Double BBU rack mounting available
• 7 AHR battery (up to 8 hours of backup, depending on load)
• Modular plug (provides quick and easy installation)
• All mounting hardware included
Unpack and Inspect the BBU
After unpacking the BBU unit, inspect it for damage. If damage is noted, file a claim with the carrier; then
contact ADTRAN Customer Service.
Batteries are retained and prewired in the BBU in a specific pattern. Battery position is maintained by foam
spacers press fitted against the housing walls. Removing batteries or disconnecting wires compromises correct
reassembly and should not be attempted.
BBU Safety and EMC Notices
• Removing the BBU covers could allow batteries to fall out.
• The BBU should only be used in specified ADTRAN applications.
• The BBU weighs in excess of 30 pounds. Arrange for assistance when handling the BBU
for mounting.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including that which may cause undesired operation.
