Option Modules
NetVanta Carrier Ethernet Quad VDSL2 EFM Module, Annex A (P/N 17406369F1)
The NetVanta Carrier Ethernet Quad VDSL2 EFM Module, Annex A (shown in
WAN-VDSL interface. See

Figure 8. NetVanta Carrier Ethernet Quad VDSL2 EFM Module, Annex A

VDSL Interface
• Four 2-wire VDSL loops
• ADSL, ADSL2, ADSL2+ fall back
compatibility
• IEEE 802.3ah EFM bonding
• MEF compliant
Clock Source
• CPE Operating Mode: Network
• CO Operating Mode: Internal
Compliance
• EMC - see Electromagnetic
Compatibility (EMC) Table on page
• UL/CUL 60950-1
• ACTA/TIA 968/FCC Part 68
• IC CS-03
• RoHS compliant

Table 6. NetVanta Carrier Ethernet Quad VDSL EFM Module, Annex A LED Behaviors

LED
SHDSL 1 through 4
30
Table A-9 on page 45 for the Quad VDSL2 connector pinouts.
QUAD VDSL ANNEX A
1 2
Features and Specifications
6.
Color
Off VDSL loop is administratively shut down.
Green (flashing) VDSL loop is training.
Green (solid) VDSL loop is trained and EFM group is established.
Amber (flashing) VDSL loop is trained but EFM group is not established.
Amber (solid) VDSL loop is in test.
Red (flashing) VDSL loop is in handshake process.
Red (solid) VDSL loop connection failure.
Copyright © 2014 ADTRAN, Inc.
NetVanta 6360 Hardware Installation Guide
Figure
4
3
Environmental
• Operating Temperature: 0°C to 50°C
(-32°F to 122°F)
• Storage Temperature: -20°C to 70°C
(-4°F to 158°F)
• Relative Humidity: Up to 95 percent,
noncondensing
Physical
• Dimensions: 6.75-inch W x 6.59-inch D
Indication
8) provides a
617006364F1-34A
