NetVanta 6360 Hardware Installation Guide
NetVanta Carrier Ethernet Quad VDSL2 EFM Module, Annex B (P/N 17406369F3)
The NetVanta Carrier Ethernet Quad VDSL2 EFM Module, Annex B (shown in
WAN-VDSL interface. See

Figure 9. NetVanta Carrier Ethernet Quad VDSL2 EFM Module, Annex B

VDSL Interface
Four 2-wire VDSL loops
ADSL, ADSL2, ADSL2+ fallout
compatibility
IEEE 802.3ah EFM bonding
MEF compliant
Clock Source
CPE Operating Mode: Network
CO Operating Mode: Internal
Compliance
EMC - see
Electromagnetic
Compatibility (EMC) Table on page
AS/ACIF S043
60950-1, Second Edition
AS/NZS 60950.1
RoHS compliant

Table 7. NetVanta Carrier Ethernet Quad VDSL2 EFM Module, Annex B LED Behaviors

LED
SHDSL 1 through 4
617006364F1-34A
Table A-9 on page 45
for the Quad VDSL2 connector pinouts.
QUAD VDSL ANNEX B
1
2
Features and Specifications
6.
Color
Off
VDSL loop is administratively shut down.
Green (flashing)
VDSL loop is training.
Green (solid)
VDSL loop is trained and EFM group is established.
Amber (flashing)
VDSL loop is trained but EFM group is not established.
Amber (solid)
VDSL loop is in test.
Red (flashing)
VDSL loop is in handshake process.
Red (solid)
VDSL loop connection failure.
Copyright © 2014 ADTRAN, Inc.
Figure
4
3
Environmental
Operating Temperature: 0°C to 50°C
(-32°F to 122°F)
Storage Temperature: -20°C to 70°C
(-4°F to 158°F)
Relative Humidity: Up to 95 percent,
noncondensing
Physical
Dimensions: 6.75-inch W x 6.59-inch D
Indication
Option Modules
9) provides a
31
