Appendix A

Table A-3. 1000Base-T Gigabit Ethernet Port Pinouts

Pin Name
1 TRD0+
2 TRD0-
3 TRD1+
4 TRD2+
5 TRD2-
6 TRD1-
7 TRD3+
8 TRD3-

Table A-4. T1/E1 Port Pinouts

Pin Name
1 RX
2 RX
3 —
4 TX
5 TX
6-8 —
42
Description
Transmit/Receive Positive
Transmit/Receive Negative
Transmit/Receive Positive
Transmit/Receive Positive
Transmit/Receive Negative
Transmit/Receive Negative
Transmit/Receive Positive
Transmit/Receive Negative
Description
Receive data from the network–Ring
Receive data from the network–Tip
Unused
Transmit data toward the network–Ring
Transmit data toward the network–Tip
Unused
