Press and hold " " for 3 seconds and the mower will switch into "TRAVEL" mode, the highest driving speed insert
for travelling and towing. The mower's blades will stop cutting.
◾
When in "TRAVEL" mode, press " ", to resume the previous speed.
NOTICE: The driving speed and driving mode cannot be adjusted during driving. The function will activiate only when the
mower wheels are stopped and the steering levers are open.

Blade-Speed Adjustment Button

Allows the user to customize the blade speed, depending on grass conditions. The user can adjust the blade speed during
grass cutting. Mowing time will be increased when mowing at lower blade speeds.
◾
+
Press " " to accelerate the blade speed and press "
◾
+
Press and hold " " for 3 seconds and the mower will switch into "TURBO" mode, the highest blade speed, to tackle
any grass condition.
◾
When in "TURBO" mode, press "
Know the LED Fuel-gauge & Status Indicator/Mower Status Indicator
◾
The LED fuel-gauge & Status indicator is located on the front of the foot-rest.
The LED fuel-gauge circle indicates the battery-charge level. The center area
indicates the mower status.
◾
The mower status indicator over the LCD screen will display the same status as
the LED fuel-gauge & status indicator center area.
◾
If the status indicator shows green, the mower is ready for driving. If the status
indicator flashes red during driving, the mower is overloaded or overheated, or
otherwise in an undesirable condition.
◾
If the status indicator is off, the mower is not ready for operator to drive. Please
see the section "STARTING THE ELECTRIC ZERO TURN MOWER" in this manual to start the mower correctly.
◾
When the available battery charge is too low, the mower will go into Limp-Home mode. The beep indicator will
sound, the status indicator will flash red every second, the first LED fuel-gauge will flash red and both the Low-
power Indicator and the battery graphics on the fuel gauge will flash. Stop working and go to the battery charging
area as soon as possible.
NOTICE: When the mower is in Limp-Home mode, the blades are automatically switched into low rotation speed without
grass cutting and the beep indicator will continue to sound. The operator should push the PTO switch downward to
disengage the blades. The beep indicator will stop sounding when the blade stops.
◾
When the battery is nearly depleted, only the first LED fuel-gauge will flash red every 0.5 seconds and the low-power
Indicator on the LCD screen will flash.

Limp-Home Mode

When the available battery charge is very low, the mower will go into Limp-Home mode. The maximum distance the
mower can travel is 0.6 mile. The operator should stop working and go to the battery charging area as soon as possible.
NOTICE: If manual pushing is needed, be sure that the batteries are disconnected from the mower and the parking-brake
pedal is released from the braking position.
-
" to decrease the blade speed.
-
", and the blade speed will resume the previous speed.
56-VOLT LITHIUM-ION ELECTRIC ZERO TURN MOWER — ZT4200L/ZT4200L-FC
5-LED Fuel Gauge
Status Indicator
