Tab. 6:

Technical Data

Tab. 7 :
Electrical data
Technical data
Technical data
Property
Backset: Tubular frame door and timber door
Distance for Swiss round cylinders
Distance for Euro profile cylinders
Follower
Function air
Deadbolt throw
Maximum door weight
(exceptions are only permitted with the written consent
of ASSA ABLOY (Schweiz) AG.)
Maximum door height
Maximum door width
Maximum pre-load
Material: Faceplate, follower, lock latch and bolt
Strength Burglar resistance
Bolt counterforce
Static lock latch load
Static bolt load
Installation position
Weight (without packaging)
Maximum unlocking time
· In escape direction (mechanical unlocking)
· With motorised unlocking
· In Day mode
Approval for fire doors
Test certificate number:
Operating temperature
Property
Nominal operating voltage as direct current (DC)
Nominal current consumption (maximum 1.5 s)
Current consumption at 24 V DC
Data cable
· Length
· Core
· Plug
Version
30 mm to 80 mm (in 5-mm steps)
94 mm
92 mm
9 mm
3 mm to 6 mm
20 mm
200 kg
2,520 mm
1,320 mm
5000 N
Stainless steel
DIN 18251 - Class 5
6,000 N
5000 N
10,000 N
Vertical
1.1 kg
1 s
1.5 s
1 s
P-14-002045-PR01-ift
-20°C – +60°C
Version
11 to 27 V DC
350 mA
10 or 20 m
LIYY 2 x 2 x 0.22 + 2 x 0.5 unscreened
Lock side (Molex)
