Combination with a swing door drive unit
For barrier-free doors Due to the integrated motorised unlocking function, the lock is suitable for combination with swing door
drive units, for example for barrier-free doors that are automatically unlocked and opened.

Access control system

Due to the motorised unlocking function, the lock can be connected to an access control system . Unlock-
Electrical unlocking
ing is then executed by an electrical impulse that can, for example, be transmitted from inside or outside
by a magnetic card reader, finger scanner or a door code system.

Daily operation

Bolt is retracted up to When Daily operation is activated, the flip latches are blocked and the bolt is retracted to 5 mm. The door
5 mm is not considered to be locked, rather just held closed. In this switching position, the lock can be unlocked
much faster by the motor or, in the case of the mFlipLock e-drive, by the coupled external lever handle.

Office function

Lock continuously The Office function enables the lock to be permanently unlocked by actuation by a permanent contact. This
unlocked means that buildings can be made accessible from outside during fixed times using an access control
system or timer.
