Siren-based alarm system

Advertisement

Siren-Based Alarm System
Installation · Programming · Operating
Keep this manual safe for reference and future maintenance
Introduction
General System Overview
Thank you for choosing the Yale Wireless Security
Alarm System. This simple to install system has
been designed with the user in mind.
The siren has a sounder and strobe LEDs to
attract attention.
Number of devices
You can install up to 20 devices in the system.
As well as extra door/window contacts, PIRs and
keypad remote controls, you can add smoke
detectors, keyfob remote controls and help buttons.
Long battery life
The system has a typical battery life of 2 years or
more before they need changing. Regular testing
and battery changes (when notified by the system)
will ensure reliability and peace of mind. Please note
that alkaline batteries and the correct type of coin
cells must be used as replacements.
Tamper proof system
Each part of the system is 'tamper' protected. Any
unauthorised tampering with the system will result in
an alarm. This feature can be turned off by the user
when a battery change is required.
Entry/Exit feature (for System with remote
keypad)
The system has a 20 second entry/exit time. This
feature allows you time to leave the home when
arming the system. Upon entering, the feature allows
time to disarm the system without causing an alarm.
Take care of your safety
Display extreme caution when using ladders or
steps, please follow manufacturer instructions. Be
careful when using hand and power tools and follow
the manufacturers' guidelines when using them.
Take care that the correct tools are used. Wear
goggles or protective clothing where required.
The external Siren is extremely loud, please
ensure you replace the cover and retreat to a safe
distance before testing.
Contents
Contents
Recommended Installation Sequence
We recommend you follow the easy start sequence,
headings numbered 1-5.
Information and illustrations are subject to change within this
document. Yale reserves the right to alter the specification and
product design at anytime without notice. Yale® is a registered
trademark. © 2010 ASSA ABLOY. All rights reserved.
2
3-4
5
6-8
9-10
11
12
14
15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSA6010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Assa Abloy HSA6010

  • Page 1: Table Of Contents

    Yale reserves the right to alter the specification and ensure you replace the cover and retreat to a safe product design at anytime without notice. Yale® is a registered distance before testing. trademark. © 2010 ASSA ABLOY. All rights reserved.
  • Page 2: Location Planning

    Location planning Work out the best places to locate the devices for maximum protection. Having chosen the locations do not mount at this stage. Operating range All devices must be within 30 metres of the siren unit and must not be mounted on or near large metal objects. Avoid obvious Siren sources of electrical interference such as fridges and microwave ovens.
  • Page 3: Unpacking The System

    Unpack all the parts on a table top The easiest way to get to know the system and get it up and running quickly is to get all the devices and accessories programmed on a table top before locating and mounting them. Yale Fixing screws X 4...
  • Page 4 Keypad remote control Keyfob remote control accessory 1 Pull out the plastic battery saver tab at the back of the remote keypad. This will activate the batteries. 1 Open the battery compartment using a coin by turning the cover in the direction of the big Keypad remote control Keyfob remote control accessory Panic...
  • Page 5: Programming The System

    Programming the Siren-based system (without control panel) The siren is the heart of the system. All components must be recognised by the siren. Entering Learn mode: Exiting Learn mode: • Press the Siren Learn button to exit the learn mode •...
  • Page 6: Mounting Alarm Devices

    Mounting alarm devices Before mounting the keypad and siren ensure that the system tamper is disabled as described below. Disabling the system tamper adjusted. Before you make the adjustment: • Disarm your system using your keyfob (Press Before mounting it is important to disable the disarm) or keypad (Press disarm followed by the system tamper to avoid the siren sounding an pincode).
  • Page 7 2 Fit wall plugs into the wall and fix cradle with the screws provided. Mounting the door/window contact Fixing Slots X 2 Frame Keypad Cradle Open Door/Window 3 Slide the keypad into the cradle Magnet 4 Close the cradle cover so the logo is facing you Sensor Gap approx 10mm Gap no more...
  • Page 8 -Mounting using screws and wall plugs The tamper switch will automatically reactivate after one hour. Alternatively you can enable the 1 Loosen the bottom screw tamper switch manually (optional). and open the door/ Knockouts window contact. See Page 10, Table 1 and Table 2 for manual tamper switch reactivation using Keypad or 2 Knock out the holes on the Keyfob.
  • Page 9: Using The System

    Using the system Arm and disarm the system and practice using it. Trigger the alarm by arming the system and opening protected doors/windows and walking past PIRs. Now’s the time to set your pin code and show the rest of the family how simple it is to use. Arming the system Changing your keypad PIN code Keypad/Keyfob: Press arm...
  • Page 10 Using the help button Keypad Modes: Table 1 Entering setting mode: Activate: Press and hold panic button for 2 Press Panic button A followed by pincode (factory seconds, the LED will light briefly and the siren will . You can now select different function. default is 0000) be activated.
  • Page 11: Adding Accessories

    Adding accessories To provide additional protection you can add extra door/window contacts, PIRs, keyfob remote controls, keypad remote controls, help buttons and smoke detectors. These are available separately from your local stockist. Keyfob Adding devices for the first time 1 Press the Arm and Home buttons together and See section 3 (page 5) for first time system continuously for 5 seconds until the LED stops installation.
  • Page 12: Changing The Batteries

    Changing the batteries Always use alkaline batteries or the correct type of coin cells as replacements because any other battery can cause problems with the operation of the system. Typical life of batteries is two years. Ensure the correct steps are taken when changing batteries in tamper protected devices. Siren 3 Using a screwdriver gently lever out the old battery.
  • Page 13 EN 300 220-1 / V2.1.1 (2006-04) EN 301 489 -1, / V1.6.1 (2004-12) EN 301 489-3, / V 1.4.1 (2002-08) EN 60 950 / 2001 + A11 + corrigendum 2004 John Ward Director Date: 16/11/06 On behalf of ASSA ABLOY Ltd.
  • Page 14: Specifications

    Specifications All devices Passive infra red (PIR) Help button Detector Radio Microprocessor controlled Environmental conditions 433.92MHz AM transmitter -10°C to 40°C, relative humidity Alarm processing Microprocessor Power supply 12V 23A/MN21 70% non-condensing for all units controlled dual edge sequential alkaline miniature ‘lighter battery’. except the external siren.
  • Page 15: Troubleshooting

    Troubleshooting www.YaleSupport.com For online assistance, please visit: Siren PIR does not respond to movement Siren does not respond to keypad • Previous movement has triggered the PIR sleep • Keypad low battery or bad connection. Check timer (see page 7) is preventing subsequent battery connections and polarity, if OK replace movement detection.
  • Page 16 Please recycle where THE ASSA ABLOY GROUP is the world’s leading facilities exist. Check with your local manufacturer and supplier of locking solutions, dedicated authority or retailer for recycling advice.
