Introduction
Thank you for choosing the Yale Telecommunicating Alarm
System. This simple to install system has been designed
with the user in mind.
All the components are self contained and no connections
are needed between the units. There is no need to
damage the home decor, lift carpets or run cables.
You can install up to 30 devices in this system. As well
as extra Door/Window Contacts, PIR's and Smoke
Detectors, you can add Key Fobs and Key Pads for added
control convenience.
There is no need to wire into the mains supply or seek
the services of a qualified electrician. The Control Panel is
powered by a plug top supply and all other components
are powered by battery (all batteries included).
Regular testing and battery changes (when notified by the
system) will ensure reliability and peace of mind.
All components are 'tamper' protected. Any unauthorised
tampering with these items will result in an alarm. This
feature can be turned off by the user when a battery
change is required.
Display extreme caution when using ladders or steps,
please follow manufacturer's instructions.
Be careful when using hand and power tools and follow
the manufacturer's guidelines when using them. Take care
that the correct tools are used. Wear goggles or protective
clothing where required.
The external Siren is extremely loud, please ensure you
replace the cover and retreat to a safe distance before
testing.
The dialling facilities must only be used with persons who
have consented to being contacted by the system.
The system is not to be used to make 999 emergency
calls directly. Yale do not hold responsibility for any actions
taken by emergency services for incorrect use of the
dialling facility.
Special Notes on Compatibility:
This alarm system is NOT compatible with HSA6000
series and HSA3000 series accessories. Please note the
prefix "EF-" in the front of the part number to indicate
compatibility (note: not compatible with accessories that
carry an "SR-" prefix).
For more information on this product and Yale Smart
Living Range visit www.yale.co.uk/smart-living
Consumer Support: info@yale.co.uk
Telecommunicating
Alarm (EF-KIT2)
Contents
Contents
Recommended Installation Sequence
We recommend you follow the simple install
sequence, headings numbered 1-6.
The 2 year guarantee for this Yale
Telecommunicating Alarm Kit is active
2
from the date of purchase (A copy
of this guarantee is available on our
website). Please register online within 12
months of purchase at www.yale.co.uk/
registeryourproduct
Information and illustrations are subject to change within this
document. Yale reserves the right to alter the specification and
product design at anytime without notice. Yale® is a registered
trademark. © 2016 ASSA ABLOY. All rights reserved.
2
4
6
8
11
17
20
22
24
26
27
Issue No: 1A
Advertisement
Table of Contents
Related Manuals for Assa Abloy Yale EF-KIT2
Summary of Contents for Assa Abloy Yale EF-KIT2
-
Page 1: Table Of Contents
“EF-” in the front of the part number to indicate product design at anytime without notice. Yale® is a registered compatibility (note: not compatible with accessories that trademark. © 2016 ASSA ABLOY. All rights reserved. carry an “SR-” prefix). Issue No: 1A For more information on this product and Yale Smart Living Range visit www.yale.co.uk/smart-living... -
Page 2: Location Planning
Location planning Work out the best places to locate the devices for maximum protection. Having chosen the locations do not mount at this stage. Home and Away Mode Planning Key Pad The Home Arming mode allows the premises to be A second Key Pad is ideal for use in bedrooms part armed so that no one can get inside without or at the top of a stairwell so the ground floor can... - Page 3 Smoke Detector External Siren • Mount in the middle of the ceiling at the top of a stairwell, or on the centre of hallway ceilings Choose a position on an external wall where the where smoke would most likely be detected. Siren would be most prominent.
-
Page 4: Unpack All The Parts
Unpack all the parts Backspace/Return Down External Siren Siren Text Display WARNING The Siren is very loud, be prepared! Take care not to activate the Siren tamper switch unnecessarily. 1. Remove the cover by unscrewing the single screw Power LED located on the lid. - Page 5 Key Fob Door/Window Contacts 1. Open the battery compartment using a coin by 1. Pull out the battery saver tab on the side to turning cover in the direction of the big arrow so Keypad remote control Keyfob remote control accessory activate the battery.
-
Page 6: First Time Easy Install
First Time Easy Set-up The installation guide will provide you with prompts to easily set-up the system. • Any omissions or mistakes can be rectified 2. Set the phone number to alert later. Once the first time install has been successfully completed it will not be shown again. - Page 7 Error Condition Next, the screen will display: (Upon selecting Exit setup) .Exit setup Repeat Setup If there are no devices/accessories (accidentally deleted) in the system and you selected “Exit Setup”, you will be prompted with “Please add at least one device”. Upon selecting “Exit Setup”, you will now be prompted with: mount devices,...
-
Page 8: Mounting Alarm Devices
Post Installation/Mounting Devices Note: Tamper is disabled during initial set-up. For details on disabling tamper see Section 6 Control Panel Mounting dc zone01 b Wall Mounting ..Using the two holes on the mounting back plate, *Note: this screen shot is use as example only. mark the position of the holes. - Page 9 1. Find a location on the door/window where you would like the device to be mounted. The sensor should be on the frame while the magnet should be on the door/window. Once mounted make sure the tamper switch spring is fully depressed. The gap between the magnet and sensor should be no more than 10mm when closed (maybe Battery tab...
- Page 10 About your alarm system (default settings) All accessories are pre-set to To change the exit and entry timer, see Chapter 5, Adv. Settings. “entry” attributes. To change the property of individual sensor (i.e. Burglar attribute where the individual sensor will When the system is first armed, user will have 30 instantly alarm when triggered), see Chapter 5, seconds to exit the building.
-
Page 11: Control Panel Menu System In Detail
Control Panel Menu System in Detail System Test Entering Programming Mode When System Test is selected, you will be given 4 The programming mode is for you to configure different options: Sensor Test, External Siren (test), the system, and make any changes to the pre-set Panel Siren (test) and Phone alert. - Page 12 · Burglar If you press any test/learn button on any learnt-in · Home Omit sensor (confirm by pressing 3), these sensors will be · Entry ignored during the Home Arm mode. · Away Entry · 24 Hour (DC only) Repeat this step to ignore additional sensors. The following devices have a fixed emergency zone type: ·...
- Page 13 4. Press 3 when completed to confirm the name • A 24 Hour Door/Window Contact is active all and return to the device list. of the time and does not have to be armed or disarmed, if triggered a burglar alarm will be activated immediately.
- Page 14 · Tamper Alarm · Mobility CHK · Siren Delay The alarm log memorises the last 30 system events · Warning Beep including: · Time · All alarm events with device names and type · Date · All fault warning events ·...
- Page 15 C.U. Siren second increments. • 30 seconds is the factory default. You can disable the Control Panel’s built-in siren with this setting. Entry Sound • Siren on is the factory default. The Control Panel will beep during the entry delay Jamming Det period as an entry warning, you can switch the sound on and off with this setting.
- Page 16 feature to be switched on and off. pressing 3. Press “Up arrow” key for * key (insert • Warning on is the factory default. 3 seconds time gap, useful for switchboard) and “Down arrow” key for the # key. Time •...
-
Page 17: Using The System
Using the System Arm and disarm the system and practice using it. Trigger the alarm by arming the system and opening protected door/windows and walking past PIRs. Now is the time to show the rest of the family how simple it is to use. Disarm The PIR Motion Detectors have a built-in sleep Disarming the System... - Page 18 • If other sensors not set to Home Omit, Entry when an audible alarm is initiated, the Control or Away Entry are triggered, the alarm will be Panel will wait for 15 seconds before dialling the activated immediately. preset phone numbers. •...
- Page 19 Disabling the system tamper Before mounting it is important to disable the External Siren and system tamper to avoid the External Siren sounding an alarm. 1. Press the Menu key and enter a user PIN code followed by 3. 2. The Control Panel is now in programming mode, Select Devices, then Program Siren and Siren Tamp.
-
Page 20: Adding And Using Accessories
Adding and using Accessories To provide additional protection you can add extra Door/Window Contacts, PIR Motion Detectors, Key Fobs, Key Pads, Panic Buttons and Smoke Detectors. These are available separately from your local stockist. Preparation Key Pad See section 2 for battery insertion, activation and Key Pad initialisation part identification. - Page 21 Using your Panic Button Using your Key Pad • The Key Pad can be used to Away Arm and Home Arm the system using the buttons as shown. Activate an Alarm • The system is disarmed by pressing the Disarm •...
-
Page 22: Changing The Batteries
Changing the Batteries Always use alkaline batteries or the correct type of coin cell batteries as replacements because any other battery can cause problems with the operation of the system. Ensure the correct steps are taken when changing batteries in tamper protected devices. Control Panel Low Battery PIR Motion Detector Battery Change When the battery is low the LED will flash when any... - Page 23 Key Fob Battery Change Panic Battery Change When the battery is low the LED will glow dimly When the battery is low the LED will glow dimly when any key is pressed. The battery is changed as when the button is pressed. The battery is changed follows: as follows: 1.
-
Page 24: Troubleshooting
Troubleshooting External Siren • Check that the PIR Motion Detector is not pointed at sources of heat or moving objects, e.g. fluttering curtains. Siren does not respond to Arming or Disarming • Check that PIR Motion Detector is not mounted above convector heaters or pointing directly at •... - Page 25 Voice - Dialler not responding to alarm _____________________________________________ • Check the telephone line is connected and Complete Reset Procedure that the correct telephone numbers have been programmed. Reset to factory default setting _____________________________________________ The Control Panel can clear all programmed RED triangle LED illuminates and parameters by the following sequence: warning beeps (every 30 seconds...
-
Page 26: Sensor Response Table
Troubleshooting Consumer Support Helpline 3. Release the p key when a tone is heard, ‘Enter Code’ will be displayed. Should you have any questions or experience a problem with your Telecommunicating Alarm Kit, please contact our 4. Enter the following key sequence: Consumer Support Helpline. -
Page 27: Specifications
Specifications All devices PIR Motion Detector Panic Button Radio 868MHz FM Alarm processing Microprocessor Environmental conditions Power supply 3V, CR2032 lithium controlled dual edge sequential -10°C to 40°C, relative humidity coin cell battery. pulse count with pulse length 70% non-condensing for all units discrimination except the external Siren. - Page 28 Please recycle where THE ASSA ABLOY GROUP is the world’s leading facilities exist. Check with your local manufacturer and supplier of locking solutions, dedicated authority or retailer for recycling advice.
