Assa Abloy Yale HSA 6400 Installation, Programming, Operating Manual

Assa Abloy Yale HSA 6400 Installation, Programming, Operating Manual

Control panel-based alarm system

Advertisement

Control Panel-Based Alarm
System
Installation · Programming · Operating
Keep this manual safe for reference and future maintenance
01902 635998
Yale Consumer Helpline
control panel alarm manual.indd 1
24/11/06 18:47:40

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Yale HSA 6400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Assa Abloy Yale HSA 6400

  • Page 1 Control Panel-Based Alarm System Installation · Programming · Operating Keep this manual safe for reference and future maintenance 01902 635998 Yale Consumer Helpline control panel alarm manual.indd 1 24/11/06 18:47:40...
  • Page 2 Information and illustrations are subject to change within this document. Yale reserves the right to alter the specification and product design at anytime without notice. Yale® is a registered trademark. © 2006 ASSA ABLOY. All rights reserved. control panel alarm manual.indd 2...
  • Page 3: Table Of Contents

    Contents Recommended Installation Sequence Contents We recommend you follow the simple install 1 Location planning sequence, headings numbered 1-6. 2 Unpack all the parts 3 First Time Easy Install 4 Mounting alarm devices 5 Control Panel Menu System in Detail 6 Using the System Adding and using Accessories Changing the batteries...
  • Page 4: Location Planning

    Location planning Work out the best places to locate the devices for maximum protection. Having chosen the locations do not mount at this stage. Home and Away Mode Planning Keypad remote control accessory The home arming mode allows the premises to be When used as second keypad, it is ideal in part armed so that no one can get inside without bedrooms or at the top of a stairwell so the...
  • Page 5 Smoke detector Siren • Mount in the middle of the ceiling at the top of a stairwell, or on the centre of hallway ceilings Choose a position on an external wall where the where smoke would most likely be detected. siren would be most prominent.
  • Page 6: Unpack All The Parts

    Unpack all the parts The easiest way to get to know the system and get it up and running quickly is to get all the devices and accessories programmed on a table top before locating and mounting them. WARNING The siren is very loud, be prepared! Take care not to activate the siren tamper switch unnecessarily.
  • Page 7 Keyfob remote control accessory 1 Open the battery compartment using a coin by turning cover in the direction of the big arrow so Keypad remote control Keyfob remote control accessory the cover small arrow is next to round dot. Keypad remote control Keyfob remote control accessory Remove the cover and insert the 3 AAA alkaline Slide off the battery cover, insert the...
  • Page 8: First Time Easy Install

    First Time Easy Install The quick install guide will prompt you to program the basic system in easy steps. Note any of the codes use the p key to select “Reset Code” and press 3, otherwise press the 3 key to •...
  • Page 9 want to send alarm messages to, you can edit the 13 “Set Date/Time (OK?)” will be shown, press 3. number by using the P key and when complete Follow the on-screen instructions to set both the press 3. More numbers can be added at this time and date.
  • Page 10: Mounting Alarm Devices

    Mounting alarm devices WARNING To prevent the alarm from activating during installation, the siren must have its tamper disabled and the control unit must be in ‘Walk Test’/Programme mode. Control Unit Mounting Mounting the siren Ensure the tamper switch is fully depressed when Table top the siren is mounted.
  • Page 11 Mounting other devices 3 Slide the keypad into the cradle Find a location where the device is to be mounted, 4 Close the cradle cover so the logo is facing you see section “Location Planning” for suggestions. Mounting the PIR Radio range test 1 Find a location where the PIR is to be mounted.
  • Page 12 Mounting the Door Contact Mounting using screws and wall plugs 1 Loosen the bottom screw and open the door/ Knockouts Frame window contact. 2 Knock out the holes on the Door/Window base as shown. 3 Drill holes into the mounting surface using the holes in the knockouts on the base as template.
  • Page 13 Final step: After mounting the siren and detectors, please enable the system tamper by: 1 Press the pr key and enter a user PIN code followed by 3. 2 The control unit is now in programming mode, Select Devices +/-, then Program Siren and Siren Tamp.
  • Page 14: Control Panel Menu System In Detail

    Control Panel Menu System in Detail Entering Programming Mode • If an up-arrow symbol p appears on the last column of the screen, it indicated the selection list can be scrolled upwards. If the highest position is The programming mode is for you to configure reached, the up-arrow symbol p disappears.
  • Page 15 Add Devices • A home omit device will be ignored when the system is home armed. • A home omit device will give a burglar alarm when 1 To learn-in a new device select ‘Add Device’ the system is away armed. then press 3, a “push Button on Device to Add”...
  • Page 16 2 If available select a zone type and press 3 to Program Siren confirm. If an outdoor siren is to be included in the system, this should be programmed in to the control unit. 3 After confirming the zone type (if available), you are To program the siren, select ‘program siren’...
  • Page 17 chronological order (most recent event first). enter a PIN code followed by 3. • The log is marked with a ‘start’ label before the • Up to 4 Pin codes can be stored. most recent entry and ‘end’ after the oldest entry. To view log: 1 Select ‘Pin Code’...
  • Page 18 Door Chime attention to itself during an alarm, to give it time to dial out on the telephone line. The delay can be set Any door contact or PIR set to entry will cause from Disable (no delay) to 10 minutes in increments the control unit to chime when activated when the of 1 minute.
  • Page 19 Rec. Address This menu allows the recording of your address. The maximum length of message is 10 seconds which is ample for most messages, when recording remember to speak clearly and slowly into the microphone. 1 Press 3 and you will be either asked to record a new message or change an old one.
  • Page 20: Using The System

    Using the System Arm and disarm the system and practice using it. Trigger the alarm by arming the system and opening protected door/windows and walking past PIRs. Now is the time to show the rest of the family how simple it is to use. Away Arm 2 The control unit will sound a long beep.
  • Page 21 Stop the Alarm and Alarm • After dialling, the control panel will wait 5 seconds then playback the messages in a loop. It will first Display play the recorded address message then the pre-recorded messages (Burglar, Emergency) depending on the nature of the alarm and finally an During an alarm, the control panel and outside siren acknowledgement request message.
  • Page 22: Adding And Using Accessories

    Adding and using Accessories To provide additional protection you can add extra door/window contacts, PIRs, keyfob remote controls, keypad remote controls, help buttons and smoke detectors. These are available separately from your local stockist. Preparation Keypad See section 2, ‘Unpack all the parts’, for battery Keypad code changing and setting insertion or activation and part identification.
  • Page 23 Using your Help Button Using your keypad • The keypad can be used to Away Arm and Home Arm the system using the buttons as shown. Activate an Alarm • The system is disarmed by pressing the disarm • Press and hold the red button for at least 2 button followed by any user code, similar to using seconds- LED will light momentarily and the alarm the control unit keypad.
  • Page 24: Changing The Batteries

    Changing the Batteries Always use alkaline batteries or the correct type of coin cells as replacements because any other battery can cause problems with the operation of the system. Typical life of batteries is two years or more. Ensure the correct steps are taken when changing batteries in tamper protected devices.
  • Page 25 Help button battery change When the battery is low the LED will glow dimly Keyfob battery change when the button is pressed. The battery is changed When the battery is low the LED will glow dimly as follows: when any key is pressed. The battery is changed as follows: 1 Loosen the bottom case screw and take button cover off base.
  • Page 26: Troubleshooting

    Troubleshooting HELPLINE 01902 635998 If you have a problem with your alarm, please call the helpline on: Lines open 8am-5pm, Mon-Fri Siren PIR gives false alarms • Check pets have no access to protected area. • Check that PIR is not pointed at sources of heat or Siren does not respond to arming or disarming moving objects, e.g.
  • Page 27 Kits with telephone dialler Reset Procedure function Reset to factory default setting The control panel can clear all programmed Voice - Dialler not responding to alarm parameters by the following sequence: • Check the telephone line is connected and that the correct telephone numbers have been 1 Power down control panel and remove the battery.
  • Page 28: Specifications

    Specifications Specifications Specifications All devices Passive infra red (PIR) Help button All devices Passive infra red (PIR) detector Power supply 3 x AAA alkaline cells. 3 All devices Passive infra red (PIR) detector Power supply 3 x AAA alkaline years typical domestic service life years typical domestic servi Detector Alarm processing Microprocessor...
  • Page 29 EN 301 489 -1, / V1.6.1 (2004-12) EN 301 489-3, / V 1.4.1 (2002-08) EN 60 950 / 2001 + A11 + corrigendum 2004 John Ward Director Date: 16/11/06 On behalf of ASSA ABLOY Ltd. control panel alarm manual.indd 29 24/11/06 18:48:20...
  • Page 30 control panel alarm manual.indd 30 24/11/06 18:48:20...
  • Page 31 control panel alarm manual.indd 31 24/11/06 18:48:20...
  • Page 32: Key Points

    School Street, Willenhall, than any other consumer locking solution. West Midlands WV13 3PW THE ASSA ABLOY GROUP is the world’s leading Tel: +44 (0)1902 364647 manufacturer and supplier of locking solutions, dedicated Fax: +44 (0)1902 364692...
