Functions and operation

Product variants

mFlipLock drive with panic function E

The mFlipLock drive is equipped with a continuous follower so that the inside and outside handles are
always coupled. Typically, a fitting with a knob is fitted on the outside (in the opposite direction to the
escape direction) and an escape route door fitting is fitted on the inside (in the escape direction).
In this product variant, the motor retracts the bolts and releases the flip latches.
Tab. 2 shows the unlocking options.
Unlocking from the outside
With a key
By electrical impulse

mFlipLock e-drive with panic function B

The mFlipLock e-drive is equipped with a split follower so that the inside handle is coupled and the outside
handle is not coupled. Typically, a fitting with a lever handle is fitted on both sides of the door, with an
escape route door fitting on the inside (in the escape direction).
In this product variant, the motor retracts the bolts for opening from the outside to 5 mm and then
couples and decouples the outside lever handle.
Tab. 3 shows the unlocking options.
Unlocking from the outside
With a key
By electrical impulse and then by the door handle By electrical impulse and then by the door handle
The bolt is initially retracted to 5 mm when unlocking from the outside. The flip latches are subsequently
released via the door handle and the door is completely unlocked.
Unlocking from the inside
With a key
By electrical impulse
With the door handle (panic fitting)
Unlocking from the inside
With a key
With the door handle (panic fitting)
