3 Components and Power Supply
WAN-2
LAN Switch
WLAN-1
(Depending on
the model)
WLAN-2
(Depending on
the model)
Cell
GPS
(Depending on
the model)
6
Base-T / SFP
LAN switch interface activity
Access Point 2.4 GHz radio
Access Point 5 GHz radio
Status
RSSI.
Coverage indication
SIM-1
SIM-2
GPS Status
Red -> Error. Interface failure.
Off -> No link or not used.
Green -> Link (1G). Blinking: traffic activity.
Amber -> Link (<1G). Blinking: traffic activity.
Red -> Error. Interface failure.
This interface is disabled by default and can be enabled by
means of a license.
Green -> connected (all connected ports at 1G). Blinking: connec-
tion data activity.
Amber -> connected (at least one port at <1G). Blinking: connec-
tion data activity.
Red -> Disconnected.
Off -> Interface off.
Off -> Radio module and/or SSIDs inactive.
Red -> No connection, or disabled (shutdown).
Amber -> Enabled, but no associated STAs.
Green -> Connected. Blinking: connection data activity.
Off -> Radio module and/or SSIDs inactive.
Red -> No connection, or disabled (shutdown).
Amber -> Enabled, but no associated STAs.
Green -> Connected. Blinking: connection data activity.
Not used on this router.
Not used on this router.
Not used on this router.
Not used on this router.
Not used on this router.
