A.5.3 WAN Base-T Interface
STANDARDS
SPEED
CONNECTOR
A.5.4 WAN SFP Interface
STANDARDS
SPEED
TYPES
CONNECTOR
A.5.5 Wireless WAN interface
WWAN Standard/Bands
CONNECTOR
SIM Slots
ANTENNA
A.5.6 GPS interface
STANDARDS
GNSS
SATELLITE CHANNELS
CONNECTOR
ANTENNA
Teldat Connect-KFPlus
Ethernet (802.3).
10/100/1000 Mbps (Base-T).
RJ45 female.
802.1Q (VLAN).
1000-Base-X.
MSA and SFF 8472 compliant.
1000 Mbps full duplex.
LX/LH (single-mode 1310 nm).
SX (multi-mode 850 nm).
ZX (single-mode 1550 nm).
Standard SFP connector.
Not used by the router.
Five SMA connectors, not used by the router.
2 Mini-SIM (2FF), not used by the router.
Not used by the router.
Not used by the router.
Not used by the router.
Not used by the router.
SMA female.
Not used by the router.
