1.2.4 Symbols for graphics
Symbol
1, 2, 3, ...
, , ...
A, B, C, ...
A-A, B-B, C-C, ...
Hazardous
Area
Hazardous
Area
1.2.5 Symbols for tools
Symbol

2 Basic Safety Instructions

2.1 Requirements for personnel

The personnel for installation, commissioning, diagnostics and
maintenance must fulfill the following requirements:
• Trained, qualified specialists must have a relevant qualification for this
specific function and task
• Are authorized by the plant owner/operator
• Are familiar with federal/national regulations
• Before beginning work, the specialist staff must have read and understood
the instructions in the Operating Instructions and supplementary
documentation as well as in the certificates (depending on the
application)
Operating Instructions - ProSense LPM1 Series Meter
Meaning
Item numbers
Series of steps
Views
Sections
Flow direction
Hazardous area
Indicates a hazardous area.
Safe area (non-hazardous area)
Indicates a non-hazardous area.
Meaning
Flat blade screwdriver
Allen key
Open-ended wrench
Torx screwdriver
