4.4 Post-installation check

4.4.1 Display unit in the panel-mount housing
• Is the seal undamaged?
• Are the mounting clips securely fastened on the housing of the device?
• Are the set screws properly tightened?
• Is the device located in the center of the panel cutout?
4.4.2 Display unit in the field housing
• Is the seal undamaged?
• Is the housing firmly screwed to the mounting plate?
• Is the mounting bracket firmly secured on the wall/pipe?
• Are the housing screws firmly tightened?

5 Wiring

Danger! Electric voltage!
• The entire connection of the device must take place while the device is
de-energized.
Only certified devices may be connected in the hazardous area
• Observe corresponding notes and wiring diagrams in the CSA-control
drawing supplement to these Operating Instructions. If you have any
questions, please do not hesitate to contact AutomationDirect.com
1-800-633-0405.
SELV/Class 2 device
• The device may only be powered by a power unit with an energy-limited
circuit in accordance with IEC 61010-1: 'SELV or Class 2 circuit'.
Device destroyed if current too high
• Do not operate the device at a voltage source without a current limiter.
Instead, operate the device only in the current loop with a transmitter.
Panel housing (LPM1-A-PNL): The terminals are located on the rear of
the housing.
Field housing (LPM1-A-ENC and LPM1-A-HAZ): The terminals are
located inside the housing. The device has two M16 cable entries. The
housing must be opened for wiring purposes.
