Husqvarna Automower Solar Hybrid Technical Manual page 77

4. AUTOCHECK, SERVICE PROGRAM
Program a spare part control box
All new spare part boxes must be programmed as they
are not programmed at the factory. If the mower is not
programmed a warning image is shown on the
mower's display (On 210 C all the indicator lamps flash
simultaneously). Autocheck Assistant also warns that
the mower must be programmed.
Solving problems when programming
If the message No contact is shown during
programming, Autocheck has lost contact with the
mower. Programming must then be repeated. Do not
leave the mower in the charging station for more than
15 minutes, if the mower is blocked as this can
damage the battery.
When you do not have contact with the mower, you
must use Manual programming:
1. Select the Manual programming checkbox.
2. Click on Download main program.
3. Select the program to be downloaded to the
mower, se Table 2: Version of the mower
program, page 10 and click Open.
If you still receive the message No contact: Perform
the following actions, one at a time. If you do not
receive any contact with the mower, continue with the
next action.
1. Put the mower in a connected charging station.
Make sure that the main switch is in the ON
position. Use Manual programming. Repeat if
necessary several times. In the event of
repeated problems you can try to change the
Baudrate under Communication in the Properties
Menu.
2. Perform a battery reset on the mower:
1.Dismantle the body.
2.Unscrew the display cover so that you can see
the connection between the battery and the
control box.
3.Turn the main switch to the OFF position.
4.Disconnect the connectors between all the
batteries and the control box.
5.Prepare manual programming in Autocheck by
clicking on Download main program, and
select program. NOTE! Wait to click Open.
6.Connect all the batteries to the control box at the
same time as you click on Open (with the
chosen program file selected).
7.Repeat if necessary several times.
3012-734
3012-735
English - 77
