4. AUTOCHECK, SERVICE PROGRAM
mower has been in the N-field and the amount of hours
the mower has been in the charging station and been
switched off by the timer function.
The Battery history is shown in the box at the bottom.
The four most recent battery tests are saved in the
battery history. For more information about the battery
capacity and how a battery check is performed see
1.14.1 Battery check on page 21.
Operating history: Copy all data to new
control box
The Copy all data to new control box function is used
when the control box on an Automower needs to be
replaced. All settings and complete operating history
in the mower can, by using this function, be saved to
a file in the Autocheck folder to then be reloaded to
the mower again when the control box has been replaced.
To copy data to the new control box:
Before replacing the control box:
1. Ensure that the mower is connected correctly and
that the main switch is turned ON.
2. Click on Save data.
This button then becomes dimmed and a new
box, Save data, is displayed. The connected
mower's serial number and the current date are
stated as the filename in the Save data as box.
You can change the filename by selecting the
name, delete it and then enter a new name.
3. Click on Save.
4. Click OK when the message Settings saved is
displayed.
When a file has been saved, the function of the box
Save data changes to Transmit data.
The Transmit data function can also be accessed by
clicking on the Transmit data button in the Copy all
data to new control box.
After replacing the control box:
5. Ensure that the mower is connected correctly and
that the main switch is turned ON.
6. Select the file you wish to transmit from the list in
the Transmit data from box.
If you would like to keep the file after it has been
transmitted to the mower you will need to
deselect the Delete file after transmission
checkbox.
7. Click on Transmit.
8. Click OK when the message Settings changed is
displayed.
