Example number 2
In this example the guide loop is longer than 200 metres (700 ft). There is a risk that the Automower stops
following the guide wire. The charging station should therefore be moved.
Non approved
3m (10ft)
Follow loop Boundary wire
Delay 11 minutes
Corridor width 6
In the figure below, the charging station has been moved to the outer edge of the working area. The guide
loop is now shorter than 200 metres (700 ft) and there is a large open area in front of the charging station.
The delay time for the boundary wire is set to 99 minutes, that is to say, deactivated, which reduces the
risk of tracks forming. Automower will find the charging station through the Irregular search method or by
following the guide wire.
Fully approved
3m (10ft)
Follow loop Boundary wire
Delay 99 minutes
Corridor width 6
3. INSTALLATION
2m (6.5ft)
Guide wire
7 minutes
10
Guide wire
7 minutes
10
2m (6.5ft)
1
Follow loop out
Direction
Distance
Proportion
2m (6.5ft)
1
2m (6.5ft)
10
Follow loop out
Direction
Distance
Proportion
3012-621
Area 1
Guide
30 metres (100 ft)
30%
3012-623
Area 1
Guide
30 metres (100 ft)
30%
