3.1.3 Connect the S5U13781R00C100 with the STM32 F4-Discovery
A connection example for the S5U13781R00C100 reference board and the STM32 F4-Discovery via SPI
is shown in Figure 3-2, Connection Example for STM32 F4-Discovery (via SPI).
If noise on the SPI signal causes problems, place a resistor of several hundred ohms between the
S5U13781R00C100 and STM 32 F4-Discovery SPI port for the purpose of noise damping.
STM32 F4-Discovery
Figure 3-1 Connection Example for STM32 F4-Discovery (via SPI)
S5U13781R00C100 Demonstration Manual
(Rev. 2.1)
Explanation of the Demo using STM32 F4-Discovery
Connect to PC
Seiko Epson Corporation
3.3V external
5V external
power supply
power supply
STM32 F4-Discovery
JP-
PIN名
JP1-1
IDD
IDD
CN3-1
SWD
SWD
CN3-3
SWD
SWD
S5U13781
JP-
PIN名
J1-1
VDDIO VDDIO
STM32 F4-Discovery
JP-
PIN名
P1-1
GND GND
P2-50 GND GND
P1-16
PA4
SPI1_NSS
P1-15
PA5 SPI1_SCK
P1-18
PA6
SPI1_MISOI
P1-17
PA7
SPI1_MOSI
3.3V external
power supply
STM32 F4-Discovery
JP-
PIN名
P2-1
GND GND
5V external
P2-2
GND GND
power supply
P2-3
5V
5V IN
P2-4
5V
5V IN
S5U13781R00C100
STM32 F4-Discovery
FUNCTION
JP-
PIN名
FUNCTION
JP1-2
IDD
IDD
CN3-2
SWD
SWD
CN3-4
SWD
SWD
S5U13781
FUNCTION
JP-
PIN名
FUNCTION
J1-2
VCC
FLASH-VCC
S5U13781
FUNCTION
JP-
PIN名
FUNCTION
J4-45
GND GND
J1-3
GND GND
J4-27 SCS# SPI CS IN
J4-28
SCK SPI SCK IN
J4-30 MISO SPI DATA
J4-29 MOSI SPI DATA IN
S5U13781
JP-
PIN名
FUNCTION
J4-1
GND GND
J4-2
GND GND
J4-3 VDDIO
3.3V IN
VDDDCDC
J3-4
3.3V IN
FUNCTION
17
