Epson S5U13781R00C100 Demonstration Manual page 12

Preparation of Demo
(3) Preparation for display demo using PC
1. Unzip the file "demo_un232h_psp1.zip" described in Table 2-1, ATM0430D5 Download File.
The Project folder "demo_um232h_psp" is created.
2. Unzip the MPSSE-SPI library "libMPSSE-SPI.zip" downloaded in Section 2.1, Instruction for
Tool Download and Install. Then the folder "libMPSSE-SPI" will be created.
3. Double click the "b.bat" icon in the folder "\libMPSSE-SPI\Release-SPI\samples".
A command window is opened. Then type "3" to select "SPI-Static".
Copy following three files from the folder "\libMPSSE-SPI\Release-SPI\samples\SPI" into the
project folder: "demo_um232h_psp".
ftd2xx.h
libMPSSE.a
libMPSSE_spi.h
This completes embedding the MPSSE-SPI library into the UM232H demo project folder:
"demo_um232h_psp".
Project folder: demo_um232h_psp
ReadMe.txt
├
EPSON_LCDC_REF.sln
├
├ ***.cpp
***.h
├
├ libMPSSE.a
├ libMPSSE.h
├ ftd2xx.h
├ pix
image*_480x272.ppm
... ├
...
image*_320x240.ppm
├
...
Contents provided by Epson are written in Italic letter.
12
Figure 2-3 Structure of the project folder (UM232H)
Seiko Epson Corporation
Contents
Solution file
Source file
Header file
MPSSE library from FTDI
MPSSE header file from FTDI
D2XX header file from FTDI
Directory for demo image data
Demo image data for PSP panel (in PPM format)
Demo image data for QVGA panel (in PPM format)
S5U13781R00C100 Demonstration Manual
(Rev. 2.1)
